Standardized Metal-Integrated Insulated Curtain Wall

Project	Standard specifications and parameters
Standard specifications of boards	Length:500≤L≤12000mm (Other specifications available) Width:200≤W≤1200mm Thickness:50mm，60mm，80mm，100mm,120mm
Material of panels	Pre-roller coated aluminum plate/stainless steel plate/copper plate/titanium zinc plate
Material of back panels	Pre-roller coated aluminum sheet
Core materials	High quality hydrophobic rock wool
Adhesives	Thermoplastic two-component polyurethane PU adhesive

product details

description1

Parameter

Surface coatings	[LUXACOTE]、[PVDF]、[POLYESTER](Other customization)
Colors	Provide colors that meet RAL standards according to design requirements
Flame spread	Class 1 (British Standard BS476 Part 7)
Surface fire resistance	Class A

Standardized Metal-Integrated Insulated Curtain Wall01

Product Overview

The NS/HP/FP series products continuously optimize new products with super creative design, integrating functionality, practicality and aesthetics to inject fresh power into the construction industry. The outstanding system advantages and diversified design combination forms help realize the integrity of modern architecture.

Standardized Metal-Integrated Insulated Curtain Wall05

Key Features

Four-Sided Box Structure

Enclosed composite structure with inner and outer panel wrapping for long-lasting insulation and extended lifespan.

Concealed Clip-Fixing System

Fixing clips concealed beneath the surface prevent penetration damage and allow thermal expansion & contraction without deformation.

Dual EPDM Sealing

Integrated dual EPDM gaskets for superior airtightness, watertightness, and reduced thermal conductivity.

Multi-Directional Installation

Supports horizontal, vertical, and diagonal layouts; vertical installation enables top-to-bottom precision assembly.

Insulated PVC Joint

Reinforced PVC connectors enhance panel strength, break thermal bridges, and allow easy disassembly & recycling.

Standardized Metal-Integrated Insulated Curtain Wall02

Performance Advantages

Energy Efficiency: Outstanding insulation reduces HVAC energy consumption.

Fire Safety: Class A fire resistance for high-security buildings.

Acoustic Comfort: 38dB sound insulation for a peaceful indoor environment.

Weather Resistance: Anti-corrosion and fade-resistant coatings for all climates.

Standardized Metal-Integrated Insulated Curtain Wall04

Applications

Commercial Complexes

Luxury Hotels

Government & Public Buildings

Industrial Facilities

Landmark High-Rises

FAQ

Are you a factory or a trading company?

We have four core factories, located in Guangdong, Hainan, Shandong, and Anhui, with our head office situated in Dongguan, China.

What products do you offer?

We have specialized in cleanroom panels, rock wool sandwich panels, metal interior decorative panels, metal roof tiles, and container houses for 15 years.

What are your payment methods?

Payment T/T and L/C.

Do you support OEM/ODM?

Yes. Whether you require personalized customization or a completely new product design from scratch, our professional R&D and production teams can provide you with comprehensive support.

Do you have experience working with governments?

Vicdowex has completed numerous projects with governments in countries such as Vietnam, Australia, Malaysia, India, and Papua New Guinea, as well as with international businesses and construction companies.

How is your after-sales service?

We are available 24/7 for any questions. A dedicated person will oversee the entire production process for each order. We provide 3D installation drawings for container houses. We can also send engineers for on-site guidance if needed, but you will be responsible for travel, food, and lodging expenses.

What information should we provide before a quote?

If you have drawings, please provide them and specify the materials used.

If you do not have drawings, please provide basic building parameters, layout, and purpose, so we can provide a free design.

Can you provide one-stop service?

Vicdowex can provide a comprehensive solution for your project, including planning, construction drawing design, production, transportation, installation, and project management.

Get in Touch with Us

We have a professional design team to design for you free of charge, which can be customized. We can mail samples to your home free of charge. The range of product batch customization is: (starting from 2,000 square meters).
